Magicycle Ocelot Step Thru Fat Tire Electric Bike

52V 15Ah

Battery

55 Miles Range

Per Charge(estimated)

750W 86Nm

High-power Motor

Tektro Mechanical

Disc Brakes

350 lbs

Payload Capacity

Max 28 MPH

With Pedal Assist

Magicycle Ocelot Step Thru Fat Tire Electric Bike

Name: Magicycle Ocelot Step Thru Fat Tire Electric Bike
Brand: MAGICYCLE
SKU: 232
Price: 1399.00 USD
Availability: InStock
Rating: 4.8 (100 reviews)

-52V 15Ah Battery
-3.0A Fast Smart Charger
-750W Hub Motor with 86Nm Torque
-Tektro Mechanical Disc Brakes
-Backlight Display
-55 Miles Range Per Charge
-Equipped with Kenda 20”x4” Tires
-Total Payload Capacity 350lbs
-Accommodates Riders 4'10" up to 6'2" Comfortably

$1,399.00 $1,999.00

Ship in 2 Business Days from US

Color

Pearl White

Space Gray

White + Rear Rack

Gray + Rear Rack

Quantity

Free Accessories Included

Full Fenders

$118.00

Repair Tool Kit

$19.00

Front Light

$25.00

2-Year Warranty

15-Day Return

Free shipping

55+ Miles Range
86 Nm Torque
TEKTRO M300 Mechanical Disc Brakes

55+: Miles Range

86 Nm: Torque

TEKTRO M300: Mechanical Disc Brakes

Ride Farther Explore Further

750W 86Nm

High-Power Motor

52V 15Ah

Battery

55 Miles

Range Per Charge (estimate)

TEKTRO M300

Mechanical Disc Brakes

Class 2/3

Max 28 MPH with Pedal Assist

Intelligent 7-level Pedal Assist

12-Magnet Cadence Sensor

Feel in Control on Magicycle Ocelot

A long journey on Magicycle Ocelot will be easy and relaxed with the butterfly-shaped handlebar, designed to avoid any soreness or pain in your back or arms. Leading a wonderful life on a Magicycle Ocelot, everything is under control.

52V 15Ah Lithium Battery

A total of 42 5000mAh cells inside this battery provide a large capacity. Compared with a 18650 cell battery, this 21700 one could bring you a longer range, stability, and safety.

Have a Fun Time with Your Pets

The 750W motor makes it easy to catch up while walking the dog. Magicycle Ocelot comes with rear rack that can mount a basket where your pets can stay inside. The unibody front mounting bracket enables you to mount a front basket, in which you can put your pets as well.

Easy Shopping Easy Life

The step-thru frame design enablesyou to get on and off the Ocelot easily. No matter you are running errandsor going to a shopping mall,you are just an Ocelot away tomake all these things more enjoy-able than ever.

Get Fitness, Burn Calories

There are 7 levels of the PAS, and the power output of each level can be adjusted, meeting different requirements for the speed while ped-aling. This is the best way to get fit and burn your calories without being exhausted. Magicycle Ocelot just makes your exercise much more interesting.

Tektro M300 Mechanical Disc Brakes

The Tektro M300 Mechanical disc brakes provide ample stopping power even in the harshest condition super sensitive brakes make even steep slopes a piece of cake.

Frame Components
Magicycle VS Other Brands

Battery box

Magicycle Ocelot's
The battery is integrated with the down tube of the frame. Moreover, it applies the double-lock design.The first one is anti-theft while the second one is made to prevent the battery from falling off by accident.

Others'
The battery box falls off easily while riding off-road

What are the Pros of the Ocelot's Battery Box?
With the battery box integrated into the down tube the frame design is simple and clean.It can also keep the battery away from dirt and sand avoiding potential damage

Basket Mounting Bracket

Magicycle Ocelot's
Unibody design

Others'
Welding brackets, lack aesthetics

What are the Pros of the Ocelot's bracket?
More solid and aesthetic

Standover Height

Magicycle Ocelot's
15.35" from the ground

Others'
≥15.35"

What are the Pros?
Easier to get on and off

Seat Stay & Chain Stay

Magicycle
Pentagonal diamond section customized die opening better rigidity, and strength

Others
Common male mold square design Cheap pipe materials on the market

What are the Pros?
High torsional strength and good body rigidity Comfortable and stable riding, easy and sensitive control

The Position of Controller

Magicycle Ocelot's
The controller is installed in an aluminum alloy box, which is welded with the frame as a whole to provide double protection

Others'
The box is exposed to the external environment and easily broken.

What are the Pros?
The Controller can be protected from external impacts like rock water, etc.

Down Tube

Magicycle
Multi-cavity variable diameter oil injection molding process, the wall thickness is designed to be 4.0mm-5.0mm process plan

Others
The industry usually has a thickness of only 3mm and is a single cavity

What are the Pros?
Solve the problems that the strength of the industry male model down tube is not enough, the riding frame is soft, and the handlebar shakes the rear wheel when going down hill

Battery 52V 15Ah lithium battery
Charger Short-circuit proof 3.0A fast smart charger
Range 30-55 miles
Controller 52V 750W FOC smart controller, Current Range 7-22Ah (IPX8)
Hub Motor 750W brushless gear motor
Recommended Rider Heights 4'10" - 6'2"

Display Backlight Display with USB Charging
Charging Time 3 - 5 Hours
Total Payload Capacity 350lbs
Weight 73lbs/33kg
Frame size 20"
Pedal Assist Intelligent 7 levels pedal assist with 12 magnet cadence sensor

Tires Kenda 20"x4.0"
Front Fork Alloy Mechanical lockout suspension fork
Brake Lever Aluminum alloy comfort grip levers with motor cutoff switch
Throttle Half twist throttle
Lights Integrated front light
Pedal Wellgo alloy pedal with reflectors
Freewheel Shimano-14-28T BROWN/BK
Bike Frame 20" 6061 Aluminum Frame
Brake Tektro Mechanical Disc Brakes

Front Light 6V LED light
Chain KMC chain
Saddle Super Soft Cushion
Stem MA-400 SSABK
Seat Post Diameter 30.9mm length 300mm
Crank 48T, 170mm forged alloy, dual-sided bashguard
Kickstand Heavy Duty Aluminum
Gearing Shimano 7 Speed Gear Shift System
Spokes 13 Gauge on the Front / 12 Gauge on the Back

A -- Total Length 67.7"
B -- Handlebar Height 42.52"
C -- Wheelbase 46.46"
D -- Chain Stay Length 12.99"
E -- Wheel Diameter 21.65"
H -- Maximum Seat to Ground Height 35.83"
I -- Minimum Seat to Ground Height 29.71"
J -- Maximum Seat to Pedal Length 35.04"
K -- Minimum Seat to Pedal Length 27.56"
L -- Standover Height 15.35"

MAGICYCLE OCELOT FAQS

Step-thru ebikes are the best choice for professional needs, if you need a bike for the office then they prove to be the best choice. No matter what kind of formal attire you have, these bikes will keep you comfortable and relaxed. You also won't need to worry about your dress getting dirty.

No. Traditionally, the construction of a step-through bike is less stable and weaker than that of a traditional model. But Magicycle Ocelot step-through bikes are designed with thicker and more durable frames to avoid deformation when going uphill. The thickness of the tube wall is designed to be 4-5mm, while the ebike industry usually has a thickness of only 3mm, and it is a single cavity. This technology solves the problem of insufficient strength of the step-over model down tube in the bike industry.

The Magicycle Ocelot belongs to Class 2.

Magicycle Ocelot should be between Min: 5 PSI ~ Max: 30 PSI.

Usually, you can check the recommended pressure on the tire sidewall which is how much you should inflate your tires.

Magicycle Ocelot is equipped with a high-quality 7-speed Shimano gear shift system. The gears are there to help you ride more efficiently on the flat, power up any hills in your area, and give you that flexibility if you run out of battery while out and about.

①Bike Repair Tool ($19 Value): We carefully selected the following repair tools according to our ebike features: 3 wrenches, 6 Allen Wrenches, and 1 screwdriver.

②Magicycle Full Fenders ($118 Value): Reducing the amount of water, mud, and grime that sprays up into your face, all over your bike and your backside is enough to warrant their use.

③Front ($25 Value): Integrated front light keeps you to be seen all the time.

Check MODELS COMPARE to select the perfect bike for you!

Sure! Here is the Dealer Map. You can put your address in and choose the nearby shop for a test drive.

Place your order now, ship in 2 working days from the warehouse in California, and another 3-7 days delivery by FedEx.

We welcome our customers to use the Magicoins! Here is an article on how to earn Magicoins.
