Switchable Sensor

Torque & Cadence Sensor Modes

750W/1500W

High-Power Motor

120+ Miles

Range Per Charge (estimate)

52V 20Ah

1040Wh Power Battery

TEKTRO 180mm

Hydraulic Disc Brakes

Class 2/3

Max 28 MPH (Pedal Assist)

Magicycle Ocelot Pro 2.0 Torque Sensor

Control your power with torque sensor

 (UL Certified)

$1,899.00
$2,499.00

Come with

Save $301.97

Full Fenders
Full Fenders
$107.99Free
Repair Tool Kit
Repair Tool Kit
$19Free
Front & Tail Lights
Front & Tail Lights
$75.98Free
Rear Rack
Rear Rack
$99Free
+ ADDED
City Biking Package A
$126.97 $95.20
+ ADDED
Cargo Package
$258.99 $169.00
+ ADDED
Set Package D
$91.97 $72.99
+ ADDED
HD Extra Large Wide-view 360° Adjustable EBike Mirrors
$59.99 $39.99
+ ADDED
Portable Bluetooth E-Bike Speaker
$49.99 $27.99
+ ADDED
Smart4U Smart E-Bike Helmet (White / M)
$79.99 $72.99
+ ADDED
Handmade Handlebar Classic Willow Basket
$62.00
- +
ADD TO CART
Sold Out
2-Year Warranty
2-Year Warranty
Free Shipping
Free Shipping
15-Day Return
15-Day Return
24/7 Support
24/7 Support
Features & Details

52V 20Ah Lithium Battery

Switchable Torque Sensor & Cadence Sensor Modes

750W/1500W Powerful Motor

Class 2/3, Top Speed 28 MPH with Pedal Assist

120+ Miles Range Per Charge (estimate)

Tektro 180mm Hydraulic Disc Brakes

Shimano 7-level Pedal Assist

Free Shipping within the 48 Continental States

What's in the Box

Ocelot Pro 2.0 Electric Bike

E-bike Manual Guide

Repair Tool Kit

Battery, Charger, Front & Tail Light, Display, Front & Rear Fenders, Rear Rack, Front & Rear Reflectors, Bell, Bike Kickstand and Left & Right Pedals

EBike Overview
Features
Size Guide
Specifications
Rider Reviews
FAQ

The Ocelot Pro 2.0 offers the ultimate smart riding experience. With its advanced torque sensor, every pedal stroke is accurately measured to provide the perfect amount of power.

Powered by a high-capacity 52V 20Ah battery, it delivers an impressive range of up to 120+ miles on a single charge. Simply press a button to experience a ride that’s more focused, comfortable, and smooth.

Switch between Torque & Cadence Sensor with One Click

Giving you the flexibility to choose your preferred riding experience for optimal comfort and performance.

Torque Sensor

Torque Sensor makes your riding more smoothly with longer range.

With a torque sensor, the electric trike can instantly detect when you're pedaling harder, such as when going uphill or accelerating.

52V 20Ah Power Battery, Beast of Long-range Go Fast, Ride Farther
52V 20Ah 1040Wh
52V 19.2Ah 998.4Wh
48V 15Ah 720Wh
48V 14Ah 672Wh
36V 20Ah 720Wh
FEATURES
Ocelot Pro 2.0 Torque Sensor Ebike
Torque Sensor
Torque Sensor
The torque sensor adjusts motor assistance based on your pedaling effort, making the ride feel more intuitive and natural. By providing power based on your pedaling force, it uses energy more efficiently, extending battery life.
1500W 100Nm Motor
1500W 100Nm Motor
With the 750W/1500W peak power output, you can reach your potential and push your limit. Embrace the true happiness and fun that comes from the power.
Tektro Hydraulic Disc Brakes
Tektro Hydraulic Disc Brakes
Stay safe wherever you go with hydraulic disc brakes. Get the amazing and responsive braking power at the flick of your fingers. You will be confident on every ride.
Color LCD Display
Color LCD Display
IPX6 grade water-resistant and premium components, the display is designed to be seen clearly even when exposed to sunlight, rain, or any other conditions. Get the real-time data on it. Come and customize your rides with it, a variety of functions are waiting for you to explore.
Down Tube
Down Tube
Multi-cavity variable diameter oil injection molding process, the wall thickness is designed to be 4.0mm-5.0mm process plan. Solve the problems that the strength of the industry male model down tube is not enough, the riding frame is soft and the handlebar shakes the rear wheel when going downhill.
left
right

Tailor-fit comfort. For every rider.
Size guide
Size Guide
Bike Dimension

40in


40in

Specifications

Hub Motor
750W/1500W(peak) 100Nm brushless gear motor
Range
120+ Miles
Sensor
Switchable Torque And Cadence Sensor Modes
Display
Color LCD Display with USB Charging
Battery
52V 20Ah lithium battery
Charger
Short-circuit proof 3.0A fast smart charger
Charging Time
4 - 6 Hours
Pedal Assist
Intelligent 7 levels pedal assist
Total Payload Capacity
Max: 450lbs
Controller
52V 750W FOC smart controller, Current Range 20~25 Amps (IPX8)
Weight
73lbs/33kg
Frame size
20"
Recommended Rider Heights
4'10" - 6'2"

Components

Tires
Kenda 20"x4.0"
Front Light
6V LED light
Front Fork
Alloy Hydraulic lockout suspension fork
Chain
KMC chain
Brake Lever
Aluminum alloy comfort grip levers with motor cutoff switch
Saddle
Super Soft Cushion
Throttle
Half twist throttle
Stem
MA-400 SSABK
Lights
Integrated front and brake lights
Seat Post
Diameter 30.9mm length 300mm
Pedal
Wellgo alloy pedal with reflectors
Crank
48T, 170mm forged alloy, dual-sided bashguard
Freewheel
Shimano-14-28T BROWN/BK
Kickstand
Heavy Duty Aluminum
Bike Frame
20" 6061 Aluminum Frame
Gearing
Shimano 7 Speed Gear Shift System
Brake
Tektro 180mm Hydraulic Disc Brakes
Spokes
13 Gauge on the Front / 12 Gauge on the Back
Rider Reviews
Magicycle Ocelot Pro - Review And Test Ride - Russ Is Right
Magicycle Ocelot Pro - eBike Overview - CitizenCycle
A Fast and Powerful Electric Bicycle! - Jeremiah Mcintosh
Magicycle Ocelot Pro, Fun for the Whole Family! - Juni Jia Mom
I Think It's The Best 2022 Fat Tire 20" x4" 750w - EbikeProducts

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Ocelot Pro 2.0 FAQ
Ocelot Pro 2.0 FAQ

Ocelot Pro 2.0 FAQ

How do I switch between torque and cadence sensor modes? How do I switch between torque and cadence sensor modes?

Simply hold the "i" button for one second to switch modes.

What's the frame difference between the Ocelot Pro 2.0 and other brands? What's the frame difference between the Ocelot Pro 2.0 and other brands?

The down tube of the Ocelot Pro 2.0 is formed by a multi-cavity oil injection process. The thickness of the tube wall is designed to be 4-5mm, while the ebike industry usually has a thickness of only 3mm, and it is a single cavity. This technology solves the problems of insufficient strength of the step-thru model down tube in the bike industry, soft frame, handlebar shaking, and rear wheel throwing when going downhill or getting off the bike.

What's the special point of the Ocelot Pro 2.0's battery box? What's the special point of the Ocelot Pro 2.0's battery box?

①The battery box adopts the hidden design, which is integrated with the lower tube of the frame, which makes the appearance of the Ocelot Pro 2.0 more elegant and smooth, evenly dividing the front and rear center of gravity of the bike to form a more compact body. ②The battery box with a dual lock design, one lock is anti-theft, and the other one is anti-fall. Prevent the battery from falling off when you‘re riding on a tough paved road, keep your battery safe.

What are the effects and functions of the hydraulic suspension front fork? What are the effects and functions of the hydraulic suspension front fork?

Alloy front suspension fork with lockout and adjustment, 80mm travel distance. The hydraulic suspension front fork allows the wheel to "travel" along the fork for a few inches. This dynamic movement helps absorb the jarring impact of rough terrain and gives the rider a more comfortable ride.

How to reach 28 mph? How to reach 28 mph?

The default speed setting is 20mph, Magicyclebike is able to reach 28mph (45km).
First, press the "+" and "-" buttons at the same time. Then the setting page shows up in the display.
Second, select the "Advanced" option and press the "i" button to open the advanced setting page.
Third, select the "Power Set" option, which determines how many levels the pedal assistance provides. The default value is 0-7. Set it to 0-5 and then press the "i" button to save it. After this, a small sub-page will come up showing the voltage percentage that is put on each level of pedal assistance. Set level 5 from 96% to 100%.
